| Capacity (kg) | 2500 |
|---|---|
| Lift stroke (mm) | 3200 |
| Height (mm) | 530 |
| Platform length (mm) | 2500 |
| Platform Width (mm) | 1200 |
| Lift time (s) | 40 |
| Net weight (kg) | |
| Motor power (kW) | 4,6 |
| Supply voltage | 400 AC 3~/N/PE |
| Frequency (Hz) | 50 |
| Rated current (A) | 9 |
| Control voltage | 24 DC |
| Power pack location (m) | EXT, 3M |
| Protection class | IP55 |
| Hydraulic oil | ISO 32 |
| Frame length (mm) | 2500 |
| Frame width (mm) | 1060 |
| Working temp (°C) | -20 - +50 |
.
Product: General data
