Capacity (kg) | 2000 |
---|---|
Lift stroke (mm) | 800 |
Height (mm) | 220 |
Platform length (mm) | 1350 |
Platform Width (mm) | 800 |
Lift time (s) | 25 |
Net weight (kg) | 215 |
Motor power (kW) | 1,43 |
Supply voltage | 3x400 AC |
Frequency (Hz) | 50 |
Rated current (A) | 3,1 |
Control voltage | 24 AC |
Power pack location (m) | INT |
Protection class | IP55 |
Hydraulic oil | ISO 32 |
Frame length (mm) | 1335 |
Frame width (mm) | 600 |
Working temp (°C) | -20 - +50 |
.
Product: General data
